What is MEGTRON PCB laminate?

There are different types of PCB materials and laminates in SMT chip factory. MEGTRON PCB laminate is designed by PanasonIC. This industry-leading PCB laminate provides high performance in any application. MEGTRON, as a PCB material brand, provides appropriate reliability, quality and function range. In addition, MEGTRON series is widely used in all walks of life.

MEGTRON PCB laminate is a multilayer and lead-free PCB material for high-performance applications. Panasonic has developed the MEGTRON series to meet certain needs of the PCB industry. MEGTRON series includes MEGTRON M, MEGTRON 7, MEGTRON 2, MEGTRON 6 and MEGTRON 4. In addition, MEGTRON PCB material has excellent dielectric system and smooth side copper to provide low loss performance.

MEGTRON is designed to provide unique features and functions. Because of its excellent thermal performance and high-speed performance, this kind of PCB laminate is favored by PCB manufacturers.

PCB laminate has some main characteristics different from other laminates. These characteristics are unique to MEGTRON PCB materials.

Low dielectric constant (Dk)

The low and medium Dk of SMT chip manufacturers are critical for high frequency and high power applications because they can reduce power loss. MEGTRON laminates have some of the best dielectric properties to help improve conductivity. In addition, MEGTRON laminates have a range of dielectric constants. For example, the Dk value of MEGTRON 6 is 3.7.

Heat resistance

MEGTRON laminate has high heat resistance. Therefore, these PCB laminates can withstand high temperatures during SMT chip processing. When integrating these laminates, you can determine that they can handle extreme temperatures. In addition, due to their high heat resistance, these laminates are well suited for applications exposed to extreme temperatures. These laminates will not cause any damage to your surface.

Low dissipation factor

The dissipation factor describes the extent to which a material can retain energy. It determines how the PCB laminate acts as an insulator. A low dissipation factor means that the material is a more efficient insulator. MEGTRON laminate has a low dissipation factor between 0.001 and 0.005. Therefore, these laminates provide reduced current leakage during operation.

Low transmission loss

All MEGTRON products in the SMT chip have low loss transmission. Most circuit boards require low transmission loss laminates because they minimize conductor and dielectric losses. Low transmission loss material is a characteristic usually required by PCB manufacturers.

High thermal conductivity

This is one of the unique properties of MEGTRON laminate in SMT processing. MEGTRON PCB laminate can effectively transfer heat and absorb heat from its environment. Materials with poor thermal conductivity will slowly absorb heat and resist the flow of heat. This material is not ideal for PCB. MEGTRON PCB laminate has high thermal conductivity, making it an ideal choice for applications.
