Multilayer circuit boards are usually defined as 10-20 or more advanced ones, whICh are more difficult to process than traditional multilayer circuit boards and require high quality and reliability. It is mainly used in communication equipment, high-end servers, medical electronics, aviation, industrial control, military and other fields. In recent years, the MARKet demand for high layer boards in communication, base stations, aviation, military and other fields is still strong.

With the rapid development of the communication equipment market in China, the high rise board market has broad prOSPects.

At present, doMEStic PCB manufacturers that can mass produce high-level PCB mainly come from foreign-funded enterprises or a few domestic funded enterprises. PCB production of high-level circuit boards requires not only higher investment in technology and equipment, but also the experience of technicians and producers.

At the same time, the customer authentication procedure of the high-level circuit board is also strict and cumbersome. Therefore, the entry threshold of high-level circuit boards into enterprises is high, and the industrial production cycle is long.

PCB average level has become an important technical indicator to measure the technical level and product structure of PCB enterprises. This paper briefly describes the main processing difficulties encountered in the production of high-level circuit boards, and introduces the control points of key production processes of high-level circuit boards for reference.

Compared with traditional PCB products, high layer PCB have the characteristics of more plate thickness, more layers, dense lines, more through holes, large cell size, thin dielectric layer, etc., and have higher requirements for internal space, inter layer alignment, impedance control and reliability.

PCB proofing

1. Difficulties in Alignment between Layers of multilayer PCB Proofing

Due to the large number of layers in the high-level panel, users have higher and higher requirements for PCB layer calibration. Generally, the alignment tolerance between layers is controlLED at 75 microns. Considering the large unit size of high-rise boards, the high temperature and humidity of the graphic conversion workshop, the dislocation overlap caused by the inconsistency of different core boards, and the positioning mode between layers, it is more difficult to control the centering of high-rise boards.

2. Difficulties in making internal circuits

High TG, high speed, high frequency, thick copper, thin dielectric layer and other special materials are used for the high layer board, which puts forward high requirements for the internal circuit fabrication and graphic size control. For example, the integrity of impedance signal transmission increases the difficulty of internal circuit manufacturing.

The width and line spacing are SMAll, the open circuit and short circuit increase, the short circuit increases, and the qualification rate is low; There are many thin line signal layers, and the probability of AOI leakage detection in the inner layer increases; The inner core plate is thin, easy to wrinkle, poor exposure, and easy to curl when etching; High level plates are mostly system boards with large unit size and high product scrap cost.

3. Difficulties in compression manufacturing

Many inner core plates and sEMI solidified plates are overlapped, and defects such as sliding plate, delamination, resin void and bubble residue are easy to appear in stamping production. In the design of the laminated structure, the heat resistance, pressure resistance, glue content and dielectric thickness of the material shall be fully considered, and a reasonable pressing scheme for the high-rise plate shall be formulated.

Due to the large number of layers, the consistency between expansion and contraction control and size coefficient compensation cannot be maintained, and the interlaminar reliability test is easy to fail due to the thin layer insulation.

4. Difficulties in PCB drilling
