How to reduce plate deformation in PCBA design
PCB deformation is a common problem in the production of electronIC products This situation will not only reduce the functions of electronic products, but also shorten their service life, reduce user experience, and bring many troubles to enterprises Therefore, reducing PCB deformation is very important for enterprises So, how to reduce the deformation of PCB design? What are the precautions?
Polychlorinated biphenyls
1. How to reduce plate deformation PCB design
1) Strengthen the rigidity of structural data
For example, in the production process, plastic products are initially used, which can be replaced by metal shells, so as to enhance their ability to resist external impact. If you do not want to change the information of the shell, you can consider adding ribs to change the stress surface, so as to change its compression strain capacity. There are also PCB designers who will use lids to enhance their strength, but such lids must be hard data to be effective.
2.) How to reduce plate deformation in PCB design, and what factors need to be considered in the production process
1) Support the circuit board through structural design to prevent its deformation
Use the front and rear enclosures, first grow a column, and then support the circuit board to reduce the impact force and impact force when electronic products fall from a high place, and try to avoid the deformation of the circuit board.

3) Buffer data reduces the impact on products
As we all know, when an electronic product falls from a high place, it will suffer a great impact, which will lead to damage or tear of the product. The solution to this problem is to select a good buffer data to reduce this impact. However, PCB designers also pointed out that this method is not applicable to all electronic products. It is only applicable to the screws fixing one end of the circuit board, which can play a buffering role. It is difficult for others to do this.
2. Factors to be considered in the design and production of polychlorinated biphenyls
1) Product Functions
For example, it covers basic requirements, product upgrade functions, additional products that can perform functions, and components that are easy to manufacture and manage.
2) ROI
At present, many manufacturers are engaged in the design and production of PCBs. Different manufacturers have different product quality, cost performance and cost. As PCB designers, we must strive to improve product quality, reduce product costs, and provide enterprises with low investment and high return options. This should be fully considered in the process of PCB design to ensure the final cost and ROI.
3) Partners
PCB design cannot be done by only one person Therefore, if you want to design a good circuit board, you must have strong team support
